Product name
Flexible Coupling 5*8
Application
Industrial Equipment
Material
Aluminium, Aluminium
Place of Origin
SUZHOU
Quick Detail
We select high-quality varieties to carefully grow by scientific planting methods. Our is green, pollution-free, safe and healthy. The procedures of material selection and processing are made by independently. Its functionality testing is in compliance with the expected standards. made of excellent materials, is wear-resistant, anti-slip, and durable, which can be widely used in sandals, leather shoes, sneakers, high heels, casual shoes, etc. As time goes by, the quality of is still good as before.
Product Description
Features:
● Integrated structure, the overall use of high-strength alu minum alloy material .● Elasticity compensates radial,angular and axial deviations.
● Shaft and axial connection without gaps suitable for for
ward and reverse rotation.
● Commonly used in encodersstepper motors
●Tightening method of positioning screw.
Aluminum Alloy Metal Bellows Setscrew Flexible Shaft Coupling Series Encoder Motor Parallel Line Top Wire Coupling 4mm~8mm
Specification
Dimension:(Unit:mm)
Model parameter | Common bore diameter d1,d2 | ΦD | L | L1 | L2 | F | M | Tightening screw torque (N.M) | ||||||||
KLD-16X17.4 | 3,4.5,6, | 16 | 17.4 | 0.55 | 1.18 | 3 | M3 | 0.7 | ||||||||
KLD-19X20 | 3,4,5,6,6.35,7,8 | 19 | 20 | 0.55 | 1.18 | 2.3 | M3 | 0.7 | ||||||||
KLD-24X25 | 4,5,6,6.35,7.8.9.10,11. | 24 | 25 | 0.55 | 1.49 | 4.25 | M4 | 1.7 | ||||||||
KLD-29X30 | 5,6,6.35,7,8,9,9.525,10,11,12,12.7 | 29 | 30 | 0.55 | 1.81 | 5.1 | M5 | 4 | ||||||||
KLD-34X35 | 8,9,9.525,10,11,12,12.7,14,15,16. | 34 | 35 | 0.8 | 2.09 | 5 | M5 | 4 | ||||||||
Processed with H7 standard tolerance. The inner diameter size marked in the table is for reference only. The inner diameter required by the customer, please contact the salesman for detailed parameters. | ||||||||||||||||
Specifications(Unit:mm)
Model parameter | Rated torque(N.m) | Allowable eccentricity (mm) | Allowable deflection angle (°) | allowable axial deviation (mm) | Maximum speed (rpm) | Static torsional stiffness (N· m/rad) | Moment of inertia (N· m) | Coupling weight (g) | ||||||||
KLD-16X17.4 | 0.75 | 0.05 | 0.5 | ±0.1 | 24000 | 200 | 2.8x10-7 | 7 | ||||||||
KLD-19X20 | 1.5 | 0.05 | 0.5 | ±0.1 | 20000 | 270 | 6.2x10-7 | 10 | ||||||||
KLD-24X25 | 2.2 | 0.05 | 0.5 | ±0.1 | 16000 | 790 | 2.0x10-6 | 22 | ||||||||
KLD-29X30 | 3 | 0.05 | 0.5 | ±0.1 | 13000 | 1400 | 5.2x10-6 | 40 | ||||||||
KLD-34X35 | 4.5 | 0.05 | 0.5 | ±0.1 | 11000 | 2200 | 1.1x10-5 | 64 | ||||||||
Remarks: The above inertia moment and various technical parameters are measured from the maximum aperture as the standard. The maximum rated torque is related to the durability of the coupling itself. The larger the outer diameter, the greater the force,and the smaller the outer diameter is. higher speed. | ||||||||||||||||
Application
Packaging:Jaw Coupling D20 L25mm Coupling Stepper Motor 5mm 8mm Plum Shaped Clamp Shaft Coupler For Servo Motor
1. Commerial Packaging: PE bags,PP bags,Bubble bags,Carton box,Wooden box for safe package.
2. According to clients' requirements.Aluminum Alloy Metal Bellows Setscrew Flexible Shaft Coupling Series Encoder Motor Parallel Line Top Wire Coupling 4mm~8mm
