China Supplier High Quality Deep Groove Ball Bearing 6204-2z/c3 2rsh 2rs1 2rs Bearings
5.0
Model Number:
Z-01, Chrome Steel
Shipping:
Support Sea freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
Lead Time:
1-10000(pieces):30(days),>10000(pieces):To be negotiated(days)
Customization:
Customized packaging (Min. Order: 10000 sets),Customized logo (Min. Order: 10000 sets),Graphic customization (Min. Order: 10000 sets)
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Certificate:
ISO9001/AS900D
Application:
Machine Tool
Feature:
CLong Life High Speed
Keywords:
Deep Groove Ball Bearings 6204-2Z/C3 2rsh 2rs1
Service:
OEM Customized Services
Number of Row
Single row
Seals Type
seal
Precision Rating
P4
Bore Size
16 - 20 mm
Structure
Deep groove ball structure
Applicable Industries
Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Retail, Construction works , Energy & Mining
Weight
1 kg
Product name
Dearing 6204-2Z/C3 2rsh 2rs1 Deep Groove Ball
Material
Hotels, Garment Shops, Building Material Shops
Place of Origin
Jiangsu, China
Type
BALL
Product Overview
is a safe and quality-reliable product with novel design and good appearance. It is available in a wide range of types and themes, making it versatile enough to meet the diverse market demands. is precisely manufactured by using top-grade raw materials and advanced machines. This product has an optimum quality and comprehensive performance. is widely used in industrial production, such as automotive spare parts, metal spare parts, construction materials, stainless steel products, and others. has million square meters of production workshop.
Product Display
●Deep groove ball bearing is simple in structure and convenient in use.
●It is the bearing with the largest production scale and the widest application range.
●Widely used in automobiles, household appliances, machine tools, motors, pumps, agricultural machinery, textile machinery and many other fields.
Product Name | Deep Groove Ball Bearing |
Model Number | 6204-2Z/C3 bearing |
Inner Diameter | 20mm |
Outer Diameter | 47mm |
Breadth | 14mm |
Weight | 0.11KG |
Product Material | Chrome steel |
Precision Grade | P0 P6 P5 P4 P2 are all available |
Cage Material | steel , brass , nylon |
Serive | Agent, OEM ,customized |
Delivery Time | Generally it is 2-5 datys if in stock,7-15 days if not stock,or it is according to customer's requirements |
Features | Long life and high quality |
High precision , low noise with strict controling of the quality | |
High loading by the advanced high-technical design | |
Most competitive price , factory direct | |
OEM service offered ,to meet the customer's requrements | |
Price Terms | EXW, FOB, CFR, CIF |
Package | PE bag+paper box+outer carton+wooden box+pallet, or as customers' requirement |
Related product: Angular Contact Ball Bearings
Cylindrical Roller Bearings
Taper Roller Bearings
pherical Roller Bearings
Spherical roller bearings
For more detailed pictures, please contact me.
Designation | Principal dimensions | Basic load ratings | Speed ratings | ||||||||
dynamic | static | Reference speed | Limiting speed | ||||||||
d[mm] | D[mm] | B[mm] | C[kN] | C0[kN] | [r/min] | [r/min] | |||||
4204 ATN9 | 20 | 47 | 18 | 17.8 | 12.5 | 24 000 | 13 000 | ||||
4304 ATN9 | 20 | 52 | 21 | 23.4 | 16 | 22 000 | 12 000 | ||||
6004 | 20 | 42 | 12 | 9.95 | 5 | 38 000 | 24 000 | ||||
6004 NR | 20 | 42 | 12 | 9.95 | 5 | 38 000 | 24 000 | ||||
6004-2RSH | 20 | 42 | 12 | 9.95 | 5 | 11 000 | |||||
6004-2RSL | 20 | 42 | 12 | 9.95 | 5 | 38 000 | 19 000 | ||||
6004-2Z | 20 | 42 | 12 | 9.95 | 5 | 38 000 | 19 000 | ||||
6004-2ZNR | 20 | 42 | 12 | 9.95 | 5 | 38 000 | 19 000 | ||||
6004-RSH | 20 | 42 | 12 | 9.95 | 5 | 11 000 | |||||
6004-RSL | 20 | 42 | 12 | 9.95 | 5 | 38 000 | 19 000 | ||||
61804 | 20 | 32 | 7 | 4.03 | 2.32 | 45 000 | 28 000 | ||||
61804-2RS1 | 20 | 32 | 7 | 4.03 | 2.32 | 13 000 | |||||
61804-2RZ | 20 | 32 | 7 | 4.03 | 2.32 | 45 000 | 22 000 | ||||
61904 | 20 | 37 | 9 | 6.37 | 3.65 | 43 000 | 26 000 | ||||
61904-2RS1 | 20 | 37 | 9 | 6.37 | 3.65 | 12 000 | |||||
61904-2RZ | 20 | 37 | 9 | 6.37 | 3.65 | 43 000 | 20 000 | ||||
6204 | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 20 000 | ||||
6204 ETN9 | 20 | 47 | 14 | 15.6 | 7.65 | 32 000 | 20 000 | ||||
6204 N | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 20 000 | ||||
6204 NR | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 20 000 | ||||
6204-2RSH | 20 | 47 | 14 | 13.5 | 6.55 | 10 000 | |||||
6204-2RSL | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 17 000 | ||||
6204-2Z | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 17 000 | ||||
6204-2ZNR | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 17 000 | ||||
6204-RSH | 20 | 47 | 14 | 13.5 | 6.55 | 10 000 | |||||
6204-Z | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 20 000 | ||||
6204-ZNR | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 20 000 | ||||
62204-2RS1 | 20 | 47 | 18 | 12.7 | 6.55 | 10 000 | |||||
62304-2RS1 | 20 | 52 | 21 | 15.9 | 7.8 | 9 500 | |||||
6304 | 20 | 52 | 15 | 16.8 | 7.8 | 30 000 | 19 000 | ||||
☞ Please click here to get the quotation ☜
KONLIDA Deep groove ball bearing Types:
1 , single row deep groove ball bearings
2 , with a dust cover single row deep groove ball bearings
3 , with a dust cover , a ring of single row deep groove ball bearings
4, the stopper grooves and snap ring of single row deep groove ball bearing outer ring
5 , ball gap deep groove ball bearings
6 , double row deep groove ball bearings
According to the sizes of deep groove ball bearings can be divided into :
( 1 ) miniature bearings ---- nominal diameter size range of 26mm below the bearing ;
( 2 ) small bearings ---- nominal diameter size range of 28-55mm bearings ;
( 3 ) small and medium sized bearing ---- nominal diameter size range of 60-115mm bearings ;
( 4) large bearing ---- nominal diameter size range of 120-190mm bearing
( 5 ) Large bearing ---- nominal diameter size range of 200-430mm bearings ;
( 6 ) large bearings ---- nominal diameter size range of 440mm or more bearings.
Our Services:
1.Customers' requirements are fully understood with abundant records made so that and customers' time can be saved.
2.We pay close attention to customers' drawings, submit them to our technicians and make correct replies.
3.We hunt for the most economical delivery service to reduce customers' cost.
4.We report the condition of production at any time to the customers.
5.After-sales service is reliable and customers' feedbacks are considered seriously.
6.The latest market trend is always provided for our customers
Application
Applications: gearboxes, instruments and meters, motors, household appliances, internal combustion engine vehicles, agricultural machinery, construction machinery.
