Quick Detail
carries out standardized production strictly according to national standards. is a qualified product that has passed the certification of national authorities. It is up to national quality standards. The design of follows the latest trends. This product tends to have more superiorities in performance. can be widely used in many industries, such as chemicals, autos, engineering, machinery manufacturing, electric appliances, and house upgrade. closely contacts and pays attention to customers.
Transmission type | ZA type (Archimedes) | ||
Number of Turbine Teeth | Z | 72 | |
Turbine Face Modulus | M | 1.6 | |
Dividing Circle Diameter | D | 115.2 | |
Helix Angle | β | 14.25° | |
Pressure Angle | α | 20° | |
Modification Coefficient | x | 0.5 | |
Number of Worm Heads | Z1 | 9 | |
Center Distance | a | 73.8±0.015 | |
Vortex Direction | Right | ||
Accuracy Class | Level 6 | GB10089 | |
Transmission Type | ZA Type (Archimedes) | Transmission Type | ZA Type | ||||
Number of Paired Screw Heads | Z1 | 1 | Number of worm heads | Z1 | 1 | ||
Turbine Face Modulus | M | 2.5 | Modulus | Mt | 2.5 | ||
Lead Angle | γ | 2°51 43.2〞 | Lead angle | γ | 3°34＇35〞（3.5763°） | ||
Helix Direction | Right | ||||||
Axial Tooth Profile Angle of Worm | α | 20° | Helix direction | Right | |||
Number of Turbine Teeth | Z2 | 35 | Axial tooth profile angle of screw rod | α | 20° | ||
Center Distance | a | 68.75±0.02 | Number of matched turbine teeth | Z2 | 50 | ||
Turbine Displacement Coefficient | X2 | 0 | Center distance | a | 82.5±0.02 | ||
Accuracy Class | Turbine6e/GB10098 | Addendum diameter | da1 | ∅45 | |||
Pairing Worm Drawing Number | GY455-5-32 | Dividing circle diameter | d1 | ∅40 | |||
Turbine Pitch Cumulative Tolerance | Fp | 0.027 | Root circle diameter | df1 | ∅34 | ||
Pitch Limit Deviation | fpt | ±0.0085 | |||||
Company Advantages
As a modern company, integrates scientific research and development, production and processing as well as marketing. And are our main products. With the keen market sense, takes the lead in developing products in the market. runs a comprehensive product supply and after-sales service system. We are committed to providing thoughtful services for customers, so as to develop their greater sense of trust for the company. has comprehensive production equipment and an experienced R&D and design team. We are able to quickly respond to customers' needs and provide professional and efficient custom services.
have quality assurance and favorable price. Why are you still hesitating? Just contact us to order!
