The tooth surface of the precision milling rack is processed by precision milling. Multiple finishing processes ensure that the deformation of the...
The tooth surface of the precision milling rack is processed by precision milling. Multiple finishing processes ensure that the deformation of the tooth surface is small and the consistency is high. The precision of the precision milling rack can reach level 5, which is high precision.
The overall rack has been quenched and tempered, except for the tooth surface, all other surfaces have been milled, and the positioning accuracy is high. The price is moderate, and it is widely used in the fields of automation, robotics, and automatic welding.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
| Range of Processing | ||
| Project | Konlida factory processing requirements range | |
| Gear Rack/Rack and Pinion/Gear Rack and Pinion | ||
| Module | M 1-20 | Konlida is mainly engaged in M1-20 module gear and the production of synchronous belt Pulley |
| Teeth | Unlimited | Unlimited |
| Pressure Angle | 20° | The pressure angle generally is 20° |
| Material | 45; 42CrMo20CrMn | plastic/nylon/stainless steel/brass/copper/aluminum/rubber/bakelite |
| Accuracy Level | DIN 3962 (DIN 867)-L5E24 | adjacent tooth pitch error FP≤0.003mm |
| Heat Treatment | scheduling, high frequency, nitriding | 45 steel-HRC45 (intermediate frequency surface quenching) 42CrMo-HRC50 (intermediate frequency quenching) 20CrMnMo-HRC58-60 (carburizing and quenching) |
| Type of Gear | Gear Rack/Rack and Pinion/Gear Rack and Pinion | |
Gear Name:Rack Gears
The tooth surface of the precision milling rack is processed by precision milling. Multiple finishing processes ensure that the deformation of the tooth surface is small and the consistency is high. The precision of the precision milling rack can reach level 5, which is high precision.
The overall rack has been quenched and tempered, except for the tooth surface, all other surfaces have been milled, and the positioning accuracy is high. The price is moderate, and it is widely used in the fields of automation, robotics, and automatic welding.
The finelyground rack has high precision DIN5, the tooth surface is finely ground by a CNC gear grinding machine, all the surfaces of the rack are ground, and the module M1-M20, the tooth top is trimmed, which is more suitable for high-speed operation.
Accuracy grade: DIN 3962 (DIN 867)-L5E24 adjacent tooth pitch error FP≤0.003mm,
Cumulative error Fp≤0.035 mm/m Optional material for frame: 45; 42CrMo20CrMn
Tooth surface hardness corresponding to different materials: 45 steel-HRC45 (intermediate frequency surface quenching) 42CrMo-HRC50 (intermediate frequency quenching) 20CrMnMo-HRC58-60 (carburizing and quenching)
Gears Keywords: plastic rack and pinion/gear rack and pinion/helical rack/gear rack/rack and pinion/helical rack and pinion/gear rack plastic
Material: S45C medium carbon steel, 42CrMo alloy steel, carbon steel, stainless steel, aluminum alloy, plastic, brass, etc.
Surface Treatment: Sandblasting, Galvanizing, Oxidizing, Phosphating, Black Coating, Grinding, etc.
Rack styles: helical, straight (straight), integrated and circular, etc.
Size : Customized
Features: Durable and wear-resistant
OEM or ODM welcome
Specializing in the production of standard and non-standard gears and racks, so we can produce various chains and sprockets according to customers' drawings and specifications and samples.
Application: packaging industry, food processing plant, plastic processing industry, label production plant, meat processing industry, cake processing industry, etc.
Our product range includes ground and milled plastic helical gear rack and pinion with straight and helical teeth. We manufacture standard and special solutions in a wide range of modules, sizes and materials as well as hardening and coating.
Contact Konlida Get drawing and quotation Oem custom machining gear Gear Type Power Transmission Gears Machinery Accessories Gears Gear Material Steel iron plastic material Small size light weight long life Gear module tooth number 49 kinds of modulus 0.1 to 45 mm Tooth number from 2 to 120 teeth 16 years CNC experience 48000㎡ factory 7 product machining craft 4 quality control Accuracy ±0.002mm Experienced team high precision low noise Imported process machine Quality inspection system 100000 dust-free workshop 3 4 5-axis equipment Surface treatment Ra1.6 Process high tolerance low wear long life gears Small batch trial order 15 working days delivery 1 piece quick proofing Oem Custom machining gear Running stability Complete specifications
